Item
Value
Pixel Pitch(mm)
6
Pixel Density(pixels/㎡)
27777
Viewing Angle(Deg.)
H: 140/ V: 140
Brightness(nits)
1800
Grey Level(bit)
16
Refresh Rate(Hz)
1920
Panel Dimension(mm)
576(W)x576(H)
Panel Dimension(inch)
22.68(W)x22.68(H)
Panel Resolution(pixels)
96×96
Panel Weight(kg)
11
Panel Type and Material
Die-casting aluminum
Module Size(mm)
288(W)x288(H)
Module Size(inch)
11.34(W)×11.34(H)
Protection Grade(Front/Rear)
IP20 / IP20 (Front / Rear)
Serviceability
Front / Rear
Avg.Power Consumption(W/㎡)
200(AC)
Max.Power Consumption(W/㎡)
600(AC)
Drive Mode
1/8 scan
Brightness Adjustment
Manual/Auto/Programmable
Operating Temp/Humidity(℃/%RH)
-20~+40/10~90
Storage Temp/Humidity(℃/%RH)
-40~+60/10~80
Lifetime(hours)
≥50000(Nomal Temp)
Compliant Standard
CE,FCC,RoHS
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to LED Cube System Sdn Bhd
