FI6 INDOOR FIXED LED DISPLAY
FI6
|
Item
|
Value
|
| Pixel Pitch(mm) |
6
|
| Pixel Density(pixels/㎡) |
27777
|
| Viewing Angle(Deg.) |
H: 140/ V: 140
|
| Brightness(nits) |
1800
|
| Grey Level(bit) |
16
|
| Refresh Rate(Hz) |
1920
|
| Panel Dimension(mm) |
960(W)x960(H)
|
| Panel Dimension(inch) |
37.80(W)x37.80(H)
|
| Panel Resolution(pixels) |
160x160
|
| Panel Weight(kg) |
37
|
| Panel Type and Material |
Iron/Aluminum
|
| Module Size(mm) |
192(W)x96(H)
|
| Module Size(inch) |
7.56(W)x3.78(H)
|
| Module Resolution(pixels) |
32x16
|
| Protection Grade(Front/Rear) |
IP20
|
| Serviceability |
Rear
|
| Avg.Power Consumption(W/㎡) |
210(AC)
|
| Max.Power Consumption(W/㎡) |
630(AC)
|
| Drive Mode |
1/8 scan
|
| Brightness Adjustment |
Manual/Auto/Programmable
|
| Operating Temp/Humidity(℃/%RH) |
-20~+40/10~90
|
| Storage Temp/Humidity(℃/%RH) |
-40~+60/10~80
|
| Lifetime(hours) |
≥50000(Nomal Temp)
|
| Compliant Standard |
CE,FCC,RoHS
|
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to LED Cube System Sdn Bhd |
|
